Name: Auto Rotary Bender Machine to Bend Rotary Steel Cutting Knife for Die Maker Materials
Brand: Graphic, Graphic
SKU: BJGR2280
Price: 45 USD
Availability: InStock
Rating: 4.9 (121 reviews)

Home > products > Steel Rule Bender Machine >

Auto Rotary Bender Machine to Bend Rotary Steel Cutting Knife for Die Maker Materials

Place of Origin:

Beijing China

Brand Name:

Graphic, Graphic

Model Number:

BJGR2280

Request A Quote

Auto Rotary Bender Machine to Bend Rotary Steel Cutting Knife for Die Maker Materials

Product Details

Place Of Origin::

Beijing, China

Application:

Laser Die Bending

Format:

DXF AI PLT

Thickness:

1pt 2pt 3pt 4pt

Function:

Auto Feeding Bending Slotting

Usage:

Cutting Rule Bending Machine

Extra Services:

Bending Bridge Cutting Lipping Broaching Nicking Perforation

Applicable Industries:

Printing Shops, Advertising Company, Printing Packing

Weight (KG):

600kgs

Payment & Shipping Terms

Minimum Order Quantity

Price

$45,000.00/sets 1-1 sets

Graphic Beijing Manual Die Cutting Machine for Creasing Matrix 0.4 Cutter Lightweight

Get Best Price

Industrial Grade Snipping Die Cutter Creasing Matrix 0.4 Scissors for Graphic Beijing

Get Best Price

Super March Manual Creasing Matrix Cutter for Die Cutter Laser Head None DWG Format

Get Best Price

Creasing Matrix Cutter with 16cm Height and Manual Functionality Design

Get Best Price

Contact Now

Product Description

with Common brand Motor from China

Basic Function	Bend/Cut	Patented bending and shearing integrated mold design
		Bridge	Automatic bridge with motor drive and bridge height. Width of bridge can be automatically adjusted according to the drawing; the head and tail bridges can be automatically processed
		Notch	Can make notch automatically according to the drawing, or done as specified position.
		Lip	Auto lip by motor drive and lipping sizes can be adjusted automatically
		Bevel Cut	Motor driven auto bevel cut, enable the curved cutting rule connection more fitable
		Perforating	Automatically make 3mm or more perforation, and the depth can be automatically adjusted

Our competitive advantaged details:

1.Self owned software and control card, and long life free maintenance and upgraded service. Can be amended any time according to customer need, meanwhile, accept origial image(flat die or rotary die),It can also be scaled for drawing process. 2.Double detection die feeding mechanism which ensures high precision bending; Full servo motor control, fast and highly precise 3."Auto chamfer cut" technology, which enables the blade jointing more perfectly 4 .At the same time, it supports automatic back opening, automatic head and tail bridge positions, automatic lipping, and automatic punching. 5.Accept auto detection of rotary notch, can be specified to notch bend. 6.Compatible to process rotary curved steel rule R220-800, curved creasing rule/Big head creasing R220-800, 1.42mm straight cutting rule, 1.42mm straight creasing rule/big head creasing rule 7.Innovative mold design, low cost and easy to replace, we offer free grinding service for local customers. 8.Smaller size of 1500x1250x1950mm to reduce transporation cost 9.Innovated moulding design, low use cost, easy replace, long life free moulding grinding service.

Auto Rotary Steel Rule Bender Comparision
Details	Graphic	Chinese competitor	Graphic Machine Advantages
Processing Diameter	220-800mm	250-700mm	We have sold more than 50sets home and abroad
Functions	Auto bend,cut,bridge,lip,punch,perforate,bevel cut	bend,cut,bridge,lip, punch,perforate	1. Our bevel cut: auto bevel cut,safe and easy.Competitor: have to swing each time for different angle.If too thick,cannot do bevel cut. 2. About lip: we can make 2 types: bevel lip and bird lip,so not easy to block paper
Cut Method	patented bend and shear integrated mold design, safe and efficient	separate shear cut, not safe	The smaller the diameter, the safer of our bend head to shear cut
Blade Design	Open blade tool box, easy to operate	Closed box	Our machine has spacious space for rule loading
Steel Rule without notch	More than 1 year home&abroad	in the exploration phase	We have rich experience on rules without notch. Stable and trustworthy
Software	Self developed and patented, Free Long Life Update & Control Card Replacement	Third party software	Software can be amended according to your request Free of charge
Graphic Operation Tips	Full Panasonic servo and high precision		Machine will automatically stop during Improper operation or when the rules run out as we have sensor system to automatically control this.

FAQ

INSTALLATION & TRAINING TERMS

1) Beijing Graphic International Co Ltd company, hereinafter referred to as Beijing Graphic, provides technical training for the operators. Training content is including training of installation, mechanical operation, and software operation. 2）Once the BUYER and the SELLER confirm the cooperation, the BUYER can send their technician(s) to the SELLER’s factory for the training. 3）Within 15 days after receipt the BUYER’s written notice, the SELLER Beijing Graphic will send the competent engineer(s) for the contract equipment’s installation, commissioning, acceptance test and training for the BUYER’s operators (max. 2 persons) for a total period of 7(seven) working days. The training of machine and software should be done by the SELLER Beijing Graphic The expenses of the SELLER’s technician(s), such as for traveling, accommodation, air tickets, and meal allowance, shall be undertake by the BUYER.

GUARANTEE

The SELLER’s guarantee that the commodity hereof is made of the best materials with first class workmanship, complies in all respects with the quality and specifications stipulated in this contract. 1.Our guarantee is 12 months. 2.Every time our technician is sent to fix any problem of the machine or upgrade the machine, the BUYER shall provide the technician(s) with round trip air tickets, hotel and food. 3.Within 12 months, the SELLER shall dispatch skilled technician(s) to carry out after-sales service in a timely manner with free fixing fee 4.Beyond 12 months, the SELLER will send an engineer in condition time for buyer’s request. The BUYER shall pay fixing fee and salary for the technician(s). It is 150USD per working day per person. 5.Upgrading is free of charge, but the technician cost is on buyer’s side.

AFTER-SALES SERVICE SUPPORT

1) After sales service support procedure is as below: Operator(s) is required to send the documents with pictures and descriptions of the concerns of the machine. Within 24 hours, our technician will make response to the concerns of the machine. 2)We will teach the operator(s) how to find the problem and give them process to resolve the problem. 3) If on line service cannot resolve it, we will send our technician to the BUYER’s site. 4) software: On-line service used as the problem-solving methods, such as Team-viewer, WeChat, WhatsApp, phone call. 5) spare parts: a. Accessories needed, normal operate damage within warranty time, accessories cost is in the SELLER’s side, ship cost is in BUY’s side; If wrong use damage or abnormal damage, all the cost is in BUY’s side. b. We suggest the BUYER prepare some normal spare parts for the quick repair. c. The accessories can be expressed in 3-7 days in the BUYER’s request if its in stock.
