Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper

Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper

Place of Origin:

Beijing, China

Brand Name:

Graphic

Model Number:

GRZ0.5*1.6mm

Contact Us
Request A Quote
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper
Product Details
Material:
Plastic
Channel Height:
0.5mm
Channel Width:
1.6mm
Punching Time:
10000-30000sheets/hour
Base Color:
White
Certificate:
As Per Customer Request
Application:
For Cardboard & Corrugated Paper Cutting Making
Finger Tape:
Imported Finger Tape And Glue
Payment Terms:
Trade Assurance Order T/T Western Union
Name:
High Quality GRB0.5*1.4mm Plastic Creasing Matrix For Die Cutter
Payment & Shipping Terms
Minimum Order Quantity
1
Price
$25.00/boxes 1-299 boxes
RELATED PRODUCTS
Good price Edge Protector Paper Creasing Tool Die Cutting Channel GRB0.4*0.8mmP Creasing Matrix online

Edge Protector Paper Creasing Tool Die Cutting Channel GRB0.4*0.8mmP Creasing Matrix

Get Best Price
Good price CE Certified Super March Quick Shipping Creasing Matrix Cutting Machines with 0.4mm Channel Height online

CE Certified Super March Quick Shipping Creasing Matrix Cutting Machines with 0.4mm Channel Height

Get Best Price
Good price Graphic Die Cutting Channel Automatic Creasing Matrix Cutter with Imported Finger Tape online

Graphic Die Cutting Channel Automatic Creasing Matrix Cutter with Imported Finger Tape

Get Best Price
Good price Punching Time 300000 Sheets/Hour Perforating Machine Paper Creasing Matrix for Die Cutting online

Punching Time 300000 Sheets/Hour Perforating Machine Paper Creasing Matrix for Die Cutting

Get Best Price
Contact Us
Contact Now
Product Description
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 0
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 1
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 2
Series
Plastic based Creasing Matrix
Type
Standard/Narrow/Off-center/Double
Material
PVC base with plastic shoulder
Punching Time
10,000-30,000 times
Application
Developed for small and medium print runs
Packing
70cm/pc,50pcs/box,10boxes/carton
Storage Period
2 years
Quality Guarantee
1 year
Notes
Matrix in rolls is available upon demands
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 3
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 4
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 5
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 6
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 7
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 8
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 9
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 10

Material characteristics

1.Plastic (PVC) –easy to extrude & chamfer, good durability, cannot delaminate

2.Pressboard – expensive, easy to chamfer, stronger durability, can delaminate

3.Pink fibre – very resistant and durable, easy to chamfer, expensive

4.Pertinax – the most durable product available but only available in smaller thicknesses and not all sizes. Impossible to chamfer, can use sand paper to chamfer.
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 11
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 12

1. Measure the length of the creasing rule
2. Mark the measurement and cut the matrix
3. Mount the cutting piece into the creasing rule with locator
4.Remove all of the backing tapes
5. Transfer the matrix to the die cutting steel plate
6.Remove all of the locators
7. Miter the sharp angle
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 13
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 14
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 15
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 16
Plastic-based Size Table
H x W mm
H x W mm
H x W mm
H x W mm
H x W mm
GRB 0.3×0.8 P
GRB 0.5 x 1.2 P
GRB 0.6 x 1.7 P
GRB 1.0 x 3.0 P
GRB 1.2 x 4.0 P
GRB 0.3×1.0 P
GRB 0.5 x 1.3 P
GRB 0.6 x 1.9 P
GRB 1.0 x 3.2 P
GRB 1.2 x 4.5 P
GRB 0.3×1.2 P
GRB 0.5 x 1.4 P
GRB 0.7 x 2.1 P
GRB 1.0 x 3.5 P
GRB 1.2 x 5.0 P
GRB 0.4×1.0 P
GRB 0.5 x 1.5 P
GRB 0.7 x 2.3 P
GRB 1.0 x 4.0 P
GRB 1.2 x 6.0 P
GRB 0.4×1.2 P
GRB 0.5 x 1.6 P
GRB 0.7 x 2.5 P
GRB 1.0 x 4.5 P
GRB 1.4 x 6.0 P
GRB 0.4×1.3 P
GRB 0.6 x 1.6 P
GRB 0.8 x 2.7 P
GRB 1.0 x 5.0 P
GRB 1.4 x 7.0 P
Calculation Formula
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 17
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 18
Method to choose creasing matrix size for cardboard paper. Size table ( subject to 23.8 mm die-cutting rules)
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 19
For instance: the thickness of the cardboard: 0.52mm; the thickness of creasing rules: 0.71mm, according to calculation formula: A=0.52≈0.5(mm); B=0.52 x 1.5 +0.71 = 1.49 ≈1.5(mm),so we should choose the size of 0.5 x 1.5.
Method to choose creasing matrix size for corrugated paper. Size table ( subject to 23.8 mm die-cutting rules)
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 20
Remarks: the above blanks just for reference and the exact specification suitable for your job should be chosen according to your actual conditions and material thickness.
Finished Box after Die Cutting
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 21
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 22
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 23
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 24
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 25
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 26
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 27
Q1: Are you factory direct?
A1:Beijing Graphic Inte’l Trade company as a professional creasing matrix and paper cutting knife manufacturer was established in 2012, specialized in die cutting creasing matrix, paper cutting knife and paper drill bits and pneumatic waste stripper and other related products.
Our products are mainly exported to USA, Canada, Europe, South America, etc.Over 120 countries and area.

Q2:What’s your product ranges?
A2: Our main product is packaging material, main product are die cutting creasing matrix, paper cutting knives , paper drill bits, pneumatic waste stripper and so on.

Q3:Do you have a special price and service for wholesale?
A3: Beijing Graphic Inte’l Trade company is keeping search a long term business cooperation with our clients as a professional creasing matrix manufacturer.
we can OEM &ODM for our cilents, fully support and assist on service, to offer you the most competitive price with high quality product.

Q4: What payment methods can I use? And how secure is my payment?
A4: Beijing Graphic Inte’l Trade company accept your payment through Paypal, Bank Transfer,Western Union,etc.

Q5:How long does it take for my order to be shipped? And how long can I receive it?
A5:Generally, your order will be shipped within 3~7 working days after your payment received by us.
Beijing Graphic Inte’l Trade company devotes to be a fastest delivery led lights supplier.

Q6: How about the warranty?
A6: Beijing Graphic Inte’l Trade company welcome you to contact us at 24 hours per day, 7 days per week, your any question will be highly appreciated. hotline: 0086-10-87227832
Die Cutting Machine Plastic Creasing Matrix GRZ0.5*1.6mm For Cardboard Corrugated Paper 28
